USB Host 

The document provides information regarding the USB Host Library. This document is split into the following sections:

Sections

USB Host

Overview 

The USB Host Library (hereinafter referred to as the Host Library) is the lowest layer of the USB Host stack that exposes a public facing API. In most cases, applications that require USB Host functionality do not need to interface with the Host Library directly. Instead, most applications use the API provided by a host class driver that is implemented on top of the Host Library.

However, you may want to use the Host Library directly for some of (but not limited to) the following reasons:

Implementation of a custom host class driver
Usage of lower level USB Host API

Features & Limitations

The Host Library has the following features:

Supports Full Speed (FS) and Low Speed (LS) Devices.
Supports all four transfer types: Control, Bulk, Interrupt, and Isochronous.
Allows multiple class drivers to run simultaneously, i.e., multiple clients of the Host Library.
A single device can be used by multiple clients simultaneously, e.g., composite devices.
The Host Library itself and the underlying Host Stack does not internally instantiate any OS tasks. The number of tasks is entirely controlled by how the Host Library interface is used. However, a general rule of thumb regarding the number of tasks is (the number of host class drivers running + 1).
Allows single Hub support (If option CONFIG_USB_HOST_HUBS_SUPPORTED is enabled).
Allows multiple Hubs support (If option CONFIG_USB_HOST_HUB_MULTI_LEVEL is enabled).

Currently, the Host Library and the underlying Host Stack has the following limitations:

Only supports Asynchronous transfers.
Only supports using one configuration. Changing to other configurations after enumeration is not supported yet.
Transfer timeouts are not supported yet.
The External Hub Driver: Supports only devices with the same speed as upstream port speed (e.g., Low-speed device won't work through Full-speed external Hub).
The External Hub Driver: Remote Wakeup feature is not supported (External Hubs are active, even if there are no devices inserted).
The External Hub Driver: Doesn't handle error cases (overcurrent handling, errors during initialization etc. are not implemented yet).
The External Hub Driver: No Interface selection. The Driver uses the first available Interface with Hub Class code (09h).
The External Port Driver: No downstream port debounce mechanism (not implemented yet)

Architecture 

Diagram of the Key Entities of USB Host Functionality — Diagram of the key entities involved in USB Host functionality

The diagram above shows the key entities that are involved when implementing USB Host functionality. These entities are:

The Host Library
Clients of the Host Library
Devices
Host Library Daemon Task

Host Library

The Host Library is the lowest public-facing API layer of the ESP-IDF USB Host Stack. Any other ESP-IDF component (such as a class driver or a user component) that needs to communicate with a connected USB device can only do so using the Host Library API either directly or indirectly.

The Host Library's API is split into two sub-sets, namely the Library API and Client API.

The Client API handles the communication between a client of the Host Library and one or more USB devices. The Client API should only be called by registered clients of the Host Library.
The Library API handles all of the Host Library processing that is not specific to a single client, such as device enumeration. Usually, the library API is called by a Host Library Daemon Task.

Clients

A client of the Host Library is a software component, such as a host class driver or user component, which utilizes the Host Library to establish communication with a USB device. Generally, each client has a one-to-one relation with a task. This implies that all Client API calls pertaining to a specific client must originate from the context of the same task.

By organizing the software components that use the Host Library's into clients, the Host Library can delegate the handling of all events specific to that client to the client's task. In other words, each client task is responsible for all the required processing and event handling associated with the USB communication that the client initiates.

Daemon Task

Although the Host Library delegates the handling of client events to the clients themselves, there are still Library events – events that are not specific to any particular client – that need to be handled. Library event handling can include things such as:

Handling USB device connection, enumeration, and disconnection
Rerouting control transfers to/from clients
Forwarding events to clients

Therefore, in addition to the client tasks, the Host Library also requires a task, which is usually the Host Library Daemon Task, to handle all of the library events.

Devices

The Host Library shields clients from the details of device handling, encompassing details such as connection, memory allocation, and enumeration. The clients are provided only with a list of already connected and enumerated devices to choose from. By default during enumeration, each device is automatically configured to use the first configuration found, namely, the first configuration descriptor returned on a Get Configuration Descriptor request. For most standard devices, the first configuration will have a bConfigurationValue of 1. If option CONFIG_USB_HOST_ENABLE_ENUM_FILTER_CALLBACK is enabled, a different bConfigurationValue can be selected, see Multiple Configuration Support for more details.

It is possible for two or more clients to simultaneously communicate with the same device as long as they are not communicating to the same interface. However, multiple clients can simultaneously communicate with the same device's default endpoint (i.e., EP0), which will result in their control transfers being serialized.

For a client to communicate with a device, the client must:

Open the device using the device's address. This lets the Host Library know that the client is using that device.
Claim the interface(s) that will be used for communication. This prevents other clients from claiming the same interface(s).
Send transfers to the endpoints of claimed interfaces. The client's task is responsible for handling its own processing and events related to USB device communication.

Usage 

The Host Library and the underlying Host Stack will not create any tasks. All tasks, namely the client tasks and the Daemon Task, need to be created by the class drivers or the user. Instead, the Host Library provides two event handler functions that handle all of the required Host Library processing, thus these functions should be called repeatedly from the client tasks and the Daemon Task. Therefore, the implementation of client tasks and the Daemon Task will be largely centered around the invocation of these event handler functions.

Host Library & Daemon Task

Basic Usage

The Host Library API provides usb_host_lib_handle_events() to handle library events. This function should be called repeatedly, typically from the Daemon Task. Some notable features regarding usb_host_lib_handle_events() are:

The function can block until a library event needs handling.
Event flags are returned on each invocation. These event flags are useful for knowing when the Host Library can be uninstalled.

A bare-bones Daemon Task would resemble something like the following code snippet:

#include "usb/usb_host.h"

void daemon_task(void *arg)
{
    ...
    bool exit = false;
    while (!exit) {
        uint32_t event_flags;
        usb_host_lib_handle_events(portMAX_DELAY, &event_flags);
        if (event_flags & USB_HOST_LIB_EVENT_FLAGS_NO_CLIENTS) {
            ...
        }
        if (event_flags & USB_HOST_LIB_EVENT_FLAGS_ALL_FREE) {
            ...
        }
        ...
    }
    ...
}

Note

See the peripherals/usb/host/usb_host_lib example for full implementation of the Daemon Task.

Lifecycle

The graph above illustrates the typical lifecycle of the Host Library with multiple clients and devices. Specifically, the example involves:

Two registered clients (Client 1 and Client 2).
Two connected devices (Device 1 and Device 2), where Client 1 communicates with Device 1 and Client 2 communicates with Device 2.

With reference to the graph above, the typical lifecycle involves the following key stages.

The Host Library is installed by calling usb_host_install().
- Installation must be done before any other Host Library API is called.
- Where usb_host_install() is called (e.g., from the Daemon Task or another task) depends on the synchronization logic between the Daemon Task, client tasks, and the rest of the system.
Once the Host Library is installed, the clients can be registered by calling usb_host_client_register().
- This is typically called from the client task, where the client task waits for a signal from the Daemon Task.
- This can be called elsewhere if necessary as long it is called after usb_host_install().
Device 1 connects and is then enumerated.
- Each registered client (in this case Client 1 and Client 2) is notified of the new device by way of the USB_HOST_CLIENT_EVENT_NEW_DEV event.
- Client 1 opens Device 1 and begins communication with it.
Similarly Device 2 connects and is enumerated.
- Client 1 and 2 are notified of a new device via a USB_HOST_CLIENT_EVENT_NEW_DEV event.
- Client 2 opens Device 2 and begins communication with it.
Device 1 suddenly disconnects.
- Client 1 is notified by way of USB_HOST_CLIENT_EVENT_DEV_GONE and begins its cleanup.
- Client 2 is not notified as it has not opened Device 1.
Client 1 completes its cleanup and deregisters by calling usb_host_client_deregister().
- This is typically called from the client task before the task exits.
- This can be called elsewhere if necessary as long as Client 1 has already completed its cleanup.
Client 2 completes its communication with Device 2. Client 2 then closes Device 2 and deregisters itself.
- The Daemon Task is notified of the deregistration of all clients by way the USB_HOST_LIB_EVENT_FLAGS_NO_CLIENTS event flag as Client 2 is the last client to deregister.
- Device 2 is still allocated (i.e., not freed), as it is still connected albeit not currently opened by any client.
The Daemon Task decides to clean up as there are no more clients.
- The Daemon Task must free Device 2 first by calling usb_host_device_free_all().
- If usb_host_device_free_all() was able to free all devices, the function will return ESP_OK indicating that all devices have been freed.
- If usb_host_device_free_all() was unable to free all devices for reasons like the device is still opened by a client, the function will return ESP_ERR_NOT_FINISHED.
- The Daemon Task must wait for usb_host_lib_handle_events() to return the USB_HOST_LIB_EVENT_FLAGS_ALL_FREE event flag in order to know when all devices have been freed.
Once the Daemon Task has verified that all clients have deregistered and all devices have been freed, it can now uninstall the Host Library by calling usb_host_uninstall().

Clients & Class Driver

Basic Usage

The Host Library API provides usb_host_client_handle_events() to handle a particular client's events. This function should be called repeatedly, typically from the client's task. Some notable features regarding usb_host_client_handle_events() are:

The function can block until a client event needs handling.
The function's primary purpose is to call the various event handling callbacks when a client event occurs.

The following callbacks are called from within usb_host_client_handle_events() thus allowing the client task to be notified of events.

The client event callback of type usb_host_client_event_cb_t delivers client event messages to the client. Client event messages indicate events such as the addition or removal of a device.
The USB transfer completion callback of type usb_transfer_cb_t indicates that a particular USB transfer previously submitted by the client has been completed.

Note

Given that the callbacks are called from within usb_host_client_handle_events(), users should avoid blocking from within the callbacks as this will result in usb_host_client_handle_events() being blocked as well, thus preventing other pending client events from being handled.

The following code snippet demonstrates a bare-bones host class driver and its client task. The code snippet contains:

A simple client task function client_task that calls usb_host_client_handle_events() in a loop.
Implementations of a client event callback and transfer completion callbacks.
Implementation of a simple state machine for the class driver. The class driver simply opens a device, sends an OUT transfer to EP1, then closes the device.

#include <string.h>
#include "usb/usb_host.h"

#define CLASS_DRIVER_ACTION_OPEN_DEV    0x01
#define CLASS_DRIVER_ACTION_TRANSFER    0x02
#define CLASS_DRIVER_ACTION_CLOSE_DEV   0x03

struct class_driver_control {
    uint32_t actions;
    uint8_t dev_addr;
    usb_host_client_handle_t client_hdl;
    usb_device_handle_t dev_hdl;
};

static void client_event_cb(const usb_host_client_event_msg_t *event_msg, void *arg)
{
    // This function is called from within usb_host_client_handle_events(). Do not block and try to keep it short
    struct class_driver_control *class_driver_obj = (struct class_driver_control *)arg;
    switch (event_msg->event) {
        case USB_HOST_CLIENT_EVENT_NEW_DEV:
            class_driver_obj->actions |= CLASS_DRIVER_ACTION_OPEN_DEV;
            class_driver_obj->dev_addr = event_msg->new_dev.address; //Store the address of the new device
            break;
        case USB_HOST_CLIENT_EVENT_DEV_GONE:
            class_driver_obj->actions |= CLASS_DRIVER_ACTION_CLOSE_DEV;
            break;
        default:
            break;
    }
}

static void transfer_cb(usb_transfer_t *transfer)
{
    // This function is called from within usb_host_client_handle_events(). Do not block and try to keep it short
    struct class_driver_control *class_driver_obj = (struct class_driver_control *)transfer->context;
    printf("Transfer status %d, actual number of bytes transferred %d\n", transfer->status, transfer->actual_num_bytes);
    class_driver_obj->actions |= CLASS_DRIVER_ACTION_CLOSE_DEV;
}

void client_task(void *arg)
{
    ... // Wait until Host Library is installed
    // Initialize class driver objects
    struct class_driver_control class_driver_obj = {0};
    // Register the client
    usb_host_client_config_t client_config = {
        .is_synchronous = false,
        .max_num_event_msg = 5,
        .async = {
            .client_event_callback = client_event_cb,
            .callback_arg = &class_driver_obj,
        }
    };
    usb_host_client_register(&client_config, &class_driver_obj.client_hdl);
    //Allocate a USB transfer
    usb_transfer_t *transfer;
    usb_host_transfer_alloc(1024, 0, &transfer);

    //Event handling loop
    bool exit = false;
    while (!exit) {
        // Call the client event handler function
        usb_host_client_handle_events(class_driver_obj.client_hdl, portMAX_DELAY);
        // Execute pending class driver actions
        if (class_driver_obj.actions & CLASS_DRIVER_ACTION_OPEN_DEV) {
            // Open the device and claim interface 1
            usb_host_device_open(class_driver_obj.client_hdl, class_driver_obj.dev_addr, &class_driver_obj.dev_hdl);
            usb_host_interface_claim(class_driver_obj.client_hdl, class_driver_obj.dev_hdl, 1, 0);
        }
        if (class_driver_obj.actions & CLASS_DRIVER_ACTION_TRANSFER) {
            // Send an OUT transfer to EP1
            memset(transfer->data_buffer, 0xAA, 1024);
            transfer->num_bytes = 1024;
            transfer->device_handle = class_driver_obj.dev_hdl;
            transfer->bEndpointAddress = 0x01;
            transfer->callback = transfer_cb;
            transfer->context = (void *)&class_driver_obj;
            usb_host_transfer_submit(transfer);
        }
        if (class_driver_obj.actions & CLASS_DRIVER_ACTION_CLOSE_DEV) {
            // Release the interface and close the device
            usb_host_interface_release(class_driver_obj.client_hdl, class_driver_obj.dev_hdl, 1);
            usb_host_device_close(class_driver_obj.client_hdl, class_driver_obj.dev_hdl);
            exit = true;
        }
        ... // Handle any other actions required by the class driver
    }

    // Cleanup class driver
    usb_host_transfer_free(transfer);
    usb_host_client_deregister(class_driver_obj.client_hdl);
    ... // Delete the client task. Signal the Daemon Task if necessary.
}

Note

An actual host class driver is likely to support many more features, thus will have a much more complex state machine. A host class driver is also likely to need to:

Be able to open multiple devices
Parse an opened device's descriptors to identify if the device is of the target class
Communicate with multiple endpoints of an interface in a particular order
Claim multiple interfaces of a device
Handle various errors

Lifecycle

The typical life cycle of a client task and class driver will go through the following stages:

Wait for some signal regarding the Host Library being installed.
Register the client via usb_host_client_register() and allocate any other class driver resources, such as allocating transfers using usb_host_transfer_alloc().
For each new device that the class driver needs to communicate with:
1. Check if the device is already connected via usb_host_device_addr_list_fill().
2. If the device is not already connected, wait for a USB_HOST_CLIENT_EVENT_NEW_DEV event from the client event callback.
3. Open the device via usb_host_device_open().
4. Parse the device and configuration descriptors via usb_host_get_device_descriptor() and usb_host_get_active_config_descriptor() respectively.
5. Claim the necessary interfaces of the device via usb_host_interface_claim().
Submit transfers to the device via usb_host_transfer_submit() or usb_host_transfer_submit_control().
Once an opened device is no longer needed by the class driver, or has disconnected, as indicated by a USB_HOST_CLIENT_EVENT_DEV_GONE event:
1. Stop any previously submitted transfers to the device's endpoints by calling usb_host_endpoint_halt() and usb_host_endpoint_flush() on those endpoints.
2. Release all previously claimed interfaces via usb_host_interface_release().
3. Close the device via usb_host_device_close().
Deregister the client via usb_host_client_deregister() and free any other class driver resources.
Delete the client task. Signal the Daemon Task if necessary.

Examples 

Host Library Examples

peripherals/usb/host/usb_host_lib demonstrates how to use the USB Host Library API to install and register a client, wait for a device connection, print the device's information, handle disconnection, and repeat these steps until a user quits the application.

Class Driver Examples

The USB Host Stack provides a number of examples that implement host class drivers using the Host Library's API.

CDC-ACM

A host class driver for the Communication Device Class (Abstract Control Model) is distributed as a managed component via the ESP Component Registry.
peripherals/usb/host/cdc/cdc_acm_host demonstrates how to use the CDC-ACM Host Driver to enable communication between ESP32-S3 and a USB CDC-ACM device.
peripherals/usb/host/cdc/cdc_acm_vcp demonstrates how to extend the CDC-ACM driver for Virtual Communication Port (VCP) devices like CP210x, FTDI FT23x or CH34x devices, and how to control the device and send data using the CDC-ACM API.
The CDC-ACM driver is also used in esp_modem examples, where it is used for communication with cellular modems.

MSC

A host class driver for the Mass Storage Class (Bulk-Only Transport) is deployed to ESP Component Registry.
peripherals/usb/host/msc demonstrates how to use USB Mass Storage Class to access, read, write, and perform operations on a USB flash drive, including handling USB reconnections and deinitializing the USB Host Stack.

HID

A host class driver for the HID (Human interface device) is distributed as a managed component via the ESP Component Registry.
peripherals/usb/host/hid demonstrates how to implement a basic USB Host HID Class Driver on ESP32-S3, enabling communication with USB HID devices like keyboards and mice, and continuously scans for their connection, fetching HID reports once connected.

UVC

A host class driver for the USB Video Device Class is distributed as a managed component via the ESP Component Registry.
peripherals/usb/host/uvc demonstrates how to capture video from a USB camera using the libuvc library and stream the video over Wi-Fi by hosting a TCP server, with the option to visualize the captured video on a PC using the provided player.py script.

Host Stack Configuration 

Non-Compliant Device Support

To support USB devices that are non-compliant in various scenarios or exhibit specific behaviors, it is possible to configure the USB Host stack.

As a USB device may be hot-plugged, it is essential to have configurable delays between power switching and device attachment, and when the device's internal power has stabilized.

Enumeration Configuration

During the process of enumerating connected USB devices, several delay values ensure the proper functioning of the device.

USB Root Hub Power-on and Connection Events Timing

The figure above shows all the delay values associated with both turning on port power with a device connected and hot-plugging a device.

After a port is reset or resumed, the USB system software is expected to provide a "recovery" interval of 10 ms before the device attached to the port is expected to respond to data transfers.
After the reset/resume recovery interval, if a device receives a SetAddress() request, the device must be able to complete processing of the request and be able to successfully complete the Status stage of the request within 50 ms.
After successful completion of the Status stage, the device is allowed a SetAddress() recovery interval of 2 ms.

Note

For more details regarding connection event timings, please refer to USB 2.0 Specification > Chapter 7.1.7.3 Connect and Disconnect Signaling.

Configurable parameters of the USB host stack can be configured with multiple options via Menuconfig.

For debounce delay, refer to CONFIG_USB_HOST_DEBOUNCE_DELAY_MS.
For reset hold interval, refer to CONFIG_USB_HOST_RESET_HOLD_MS.
For reset recovery interval, refer to CONFIG_USB_HOST_RESET_RECOVERY_MS.
For SetAddress() recovery interval, refer to CONFIG_USB_HOST_SET_ADDR_RECOVERY_MS.

Downstream Port Configuration

When external Hubs feature is supported, there are several parameters which could be configured for the external Hubs port.

Each external Hub has a Hub Descriptor which describes the device characteristics.

Note

For detailed information about Hub Descriptor, please refer to USB 2.0 Specification > Chapter 11.23.2.1 Hub Descriptor.

Configurable parameters of the downstream port can be configured with multiple options via Menuconfig.

For custom value to stabilize the power after powering on the port (PwrOn2PwrGood value), refer to CONFIG_USB_HOST_EXT_PORT_CUSTOM_POWER_ON_DELAY_MS.
For reset recovery interval, refer to CONFIG_USB_HOST_EXT_PORT_RESET_RECOVERY_DELAY_MS.

Note

The specification claims, that for a hub with no power switches, PwrOn2PwrGood must be set to zero. Meanwhile, for some devices, this value could be increased to give extra time for device to power-up. To enable this feature, refer to CONFIG_USB_HOST_EXT_PORT_CUSTOM_POWER_ON_DELAY_ENABLE.

Host Channels

When external Hubs support feature is enabled (CONFIG_USB_HOST_HUBS_SUPPORTED), the amount of Host channels plays important role, as each downstream device requires vacant channel.

To handle each attached device, different amount of channels are required. This amount does depend on the device class (EPs number).

Supported amount of channels for ESP32-S3 is {OTG_NUM_HOST_CHAN}.

Note

One free channel is required to enumerate the device.
From 1 to N (when N - number of EPs) free channels are required to claim the interface.
When there are no more free Host channels available, the device could not be enumerated and its interface cannot be claimed.

Multiple Configuration Support

To support USB devices that have more than one configuration, it is possible to specify the desired configuration number during a device's enumeration process.

Enumeration Filter

The enumeration filter is a callback function of type usb_host_enum_filter_cb_t called at the beginning of the enumeration process once a device descriptor is read from a newly attached USB device. Consequently, the user is provided with the obtained device descriptor. Through this callback, the user can:

Select the configuration of the USB device.
Filter which USB devices should be enumerated.

To use the enumeration filter, users should enable the CONFIG_USB_HOST_ENABLE_ENUM_FILTER_CALLBACK option using menuconfig. Users can specify the callback by setting usb_host_config_t::enum_filter_cb which is then passed to the Host Library when calling usb_host_install().

API Reference 

The API of the USB Host Library is separated into the following header files. However, it is sufficient for applications to only #include "usb/usb_host.h" and all USB Host Library headers will also be included.

usb/include/usb/usb_host.h contains the functions and types of the USB Host Library.
usb/include/usb/usb_helpers.h contains various helper functions that are related to the USB protocol such as descriptor parsing.
usb/include/usb/usb_types_stack.h contains types that are used across multiple layers of the USB Host stack.
usb/include/usb/usb_types_ch9.h contains types and macros related to Chapter 9 of the USB2.0 specification, i.e., descriptors and standard requests.

Header File

components/usb/include/usb/usb_host.h
This header file can be included with:
#include "usb/usb_host.h"
This header file is a part of the API provided by the usb component. To declare that your component depends on usb, add the following to your CMakeLists.txt:
REQUIRES usb
or
PRIV_REQUIRES usb

Functions

esp_err_t usb_host_install(const usb_host_config_t *config)

Install the USB Host Library.

This function should be called only once to install the USB Host Library
This function should be called before any other USB Host Library functions are called

Note

If skip_phy_setup is set in the install configuration, the user is responsible for ensuring that the underlying Host Controller is enabled and the USB PHY (internal or external) is already setup before this function is called.

Parameters

config -- [in] USB Host Library configuration

Returns

ESP_OK: USB Host installed successfully
ESP_ERR_INVALID_ARG: Invalid argument
ESP_ERR_INVALID_STATE: USB Host Library is not in correct state to be installed (eg. the library itself of one of it's drivers is already installed)
ESP_ERR_NO_MEM: Insufficient memory

esp_err_t usb_host_uninstall(void)

Uninstall the USB Host Library.

This function should be called to uninstall the USB Host Library, thereby freeing its resources
All clients must have been deregistered before calling this function
All devices must have been freed by calling usb_host_device_free_all() and receiving the USB_HOST_LIB_EVENT_FLAGS_ALL_FREE event flag

Note

If skip_phy_setup was set when the Host Library was installed, the user is responsible for disabling the underlying Host Controller and USB PHY (internal or external).

Returns

ESP_OK: USB Host uninstalled successfully
ESP_ERR_INVALID_STATE: USB Host Library is not installed, or has unfinished actions

esp_err_t usb_host_lib_handle_events(TickType_t timeout_ticks, uint32_t *event_flags_ret)

Handle USB Host Library events.

This function handles all of the USB Host Library's processing and should be called repeatedly in a loop
Check event_flags_ret to see if an flags are set indicating particular USB Host Library events
This function should never be called by multiple threads simultaneously

Note

This function can block

Parameters

timeout_ticks -- [in] Timeout in ticks to wait for an event to occur
event_flags_ret -- [out] Event flags that indicate what USB Host Library event occurred.

Returns

ESP_OK: No events to be handled
ESP_ERR_INVALID_STATE: USB Host Library is not installed
ESP_ERR_TIMEOUT: Semaphore waiting for events has timed out

esp_err_t usb_host_lib_unblock(void)

Unblock the USB Host Library handler.

This function simply unblocks the USB Host Library event handling function (usb_host_lib_handle_events())

Returns

ESP_OK: USB Host library unblocked successfully
ESP_ERR_INVALID_STATE: USB Host Library is not installed

esp_err_t usb_host_lib_info(usb_host_lib_info_t *info_ret)

Get current information about the USB Host Library.

Parameters

info_ret -- [out] USB Host Library Information

Returns

ESP_OK: USB Host Library info obtained successfully
ESP_ERR_INVALID_STATE: USB Host Library is not installed
ESP_ERR_INVALID_ARG: Invalid argument

esp_err_t usb_host_lib_set_root_port_power(bool enable)

Power the root port ON or OFF.

Powering ON the root port will allow device connections to occur
Powering OFF the root port will disconnect all devices downstream off the root port and prevent any further device connections.

Note

If 'usb_host_config_t.root_port_unpowered' was set on USB Host Library installation, users must call this function to power ON the root port before any device connections can occur.

Parameters

enable -- [in] True to power the root port ON, false to power OFF

Returns

ESP_OK: Root port power enabled/disabled
ESP_ERR_INVALID_STATE: Root port already powered or HUB driver not installed

esp_err_t usb_host_client_register(const usb_host_client_config_t *client_config, usb_host_client_handle_t *client_hdl_ret)

Register a client of the USB Host Library.

This function registers a client of the USB Host Library
Once a client is registered, its processing function usb_host_client_handle_events() should be called repeatedly

Parameters

client_config -- [in] Client configuration
client_hdl_ret -- [out] Client handle

Returns

ESP_OK: USB Host Library client registered successfully
ESP_ERR_INVALID_STATE: USB Host Library is not installed
ESP_ERR_INVALID_ARG: Invalid argument
ESP_ERR_NO_MEM: Insufficient memory

esp_err_t usb_host_client_deregister(usb_host_client_handle_t client_hdl)

Deregister a USB Host Library client.

This function deregisters a client of the USB Host Library
The client must have closed all previously opened devices before attempting to deregister

Parameters

client_hdl -- [in] Client handle

Returns

ESP_OK: USB Host Library client deregistered successfully
ESP_ERR_INVALID_ARG: Invalid argument

esp_err_t usb_host_client_handle_events(usb_host_client_handle_t client_hdl, TickType_t timeout_ticks)

USB Host Library client processing function.

This function handles all of a client's processing and should be called repeatedly in a loop
For a particular client, this function should never be called by multiple threads simultaneously

Note

This function can block

Parameters

client_hdl -- [in] Client handle
timeout_ticks -- [in] Timeout in ticks to wait for an event to occur

Returns

ESP_OK: No event to be handled
ESP_ERR_INVALID_STATE: USB Host Library is not installed
ESP_ERR_INVALID_ARG: Invalid argument
ESP_ERR_TIMEOUT: Semaphore waiting for events has timed out

esp_err_t usb_host_client_unblock(usb_host_client_handle_t client_hdl)

Unblock a client.

This function simply unblocks a client if it is blocked on the usb_host_client_handle_events() function.
This function is useful when need to unblock a client in order to deregister it.

Parameters

client_hdl -- [in] Client handle

Returns

ESP_OK: Client unblocked successfully
ESP_ERR_INVALID_ARG: Invalid argument

esp_err_t usb_host_device_open(usb_host_client_handle_t client_hdl, uint8_t dev_addr, usb_device_handle_t *dev_hdl_ret)

Open a device.

This function allows a client to open a device
A client must open a device first before attempting to use it (e.g., sending transfers, device requests etc.)

Parameters

client_hdl -- [in] Client handle
dev_addr -- [in] Device's address
dev_hdl_ret -- [out] Device's handle

Returns

ESP_OK: Device opened successfully
ESP_ERR_INVALID_ARG: Invalid argument

esp_err_t usb_host_device_close(usb_host_client_handle_t client_hdl, usb_device_handle_t dev_hdl)

Close a device.

This function allows a client to close a device
A client must close a device after it has finished using the device (claimed interfaces must also be released)
A client must close all devices it has opened before de-registering

Note

This function can block

Parameters

client_hdl -- [in] Client handle
dev_hdl -- [in] Device handle

Returns

ESP_OK: Device closed successfully
ESP_ERR_INVALID_ARG: Invalid argument
ESP_ERR_NOT_FOUND: Device address not found among opened devices
ESP_ERR_INVALID_STATE: The client never opened the device, or the client has not released all the interfaces from the device

esp_err_t usb_host_device_free_all(void)

Indicate that all devices can be freed when possible.

This function marks all devices as waiting to be freed
If a device is not opened by any clients, it will be freed immediately
If a device is opened by at least one client, the device will be free when the last client closes that device.
Wait for the USB_HOST_LIB_EVENT_FLAGS_ALL_FREE flag to be set by usb_host_lib_handle_events() in order to know when all devices have been freed
This function is useful when cleaning up devices before uninstalling the USB Host Library

Returns

ESP_OK: All devices already freed (i.e., there were no devices)
ESP_ERR_INVALID_STATE: Client must be deregistered
ESP_ERR_NOT_FINISHED: There are one or more devices that still need to be freed, wait for USB_HOST_LIB_EVENT_FLAGS_ALL_FREE event

esp_err_t usb_host_device_addr_list_fill(int list_len, uint8_t *dev_addr_list, int *num_dev_ret)

Fill a list of device address.

This function fills an empty list with the address of connected devices
The Device addresses can then used in usb_host_device_open()
If there are more devices than the list_len, this function will only fill up to list_len number of devices.

Parameters

list_len -- [in] Length of the empty list
dev_addr_list -- [inout] Empty list to be filled
num_dev_ret -- [out] Number of devices

Returns

ESP_OK: Device list filled successfully
ESP_ERR_INVALID_ARG: Invalid argument

esp_err_t usb_host_device_info(usb_device_handle_t dev_hdl, usb_device_info_t *dev_info)

Get device's information.

This function gets some basic information of a device
The device must be opened first before attempting to get its information

Note

This function can block

Parameters

dev_hdl -- [in] Device handle
dev_info -- [out] Device information

Returns

ESP_OK: Device information obtained successfully
ESP_ERR_INVALID_ARG: Invalid argument

esp_err_t usb_host_get_device_descriptor(usb_device_handle_t dev_hdl, const usb_device_desc_t **device_desc)

Get device's device descriptor.

A client must call usb_host_device_open() first
No control transfer is sent. The device's descriptor is cached on enumeration
This function simple returns a pointer to the cached descriptor

Note

No control transfer is sent. The device's descriptor is cached on enumeration

Parameters

dev_hdl -- [in] Device handle
device_desc -- [out] Device descriptor

Returns

ESP_OK: Device descriptor obtained successfully
ESP_ERR_INVALID_ARG: Invalid argument

esp_err_t usb_host_get_active_config_descriptor(usb_device_handle_t dev_hdl, const usb_config_desc_t **config_desc)

Get device's active configuration descriptor.

A client must call usb_host_device_open() first
No control transfer is sent. The device's active configuration descriptor is cached on enumeration
This function simple returns a pointer to the cached descriptor

Note

This function can block

Note

No control transfer is sent. A device's active configuration descriptor is cached on enumeration

Parameters

dev_hdl -- [in] Device handle
config_desc -- [out] Configuration descriptor

Returns

ESP_OK: Active configuration descriptor obtained successfully
ESP_ERR_INVALID_ARG: Invalid argument

esp_err_t usb_host_get_config_desc(usb_host_client_handle_t client_hdl, usb_device_handle_t dev_hdl, uint8_t bConfigurationValue, const usb_config_desc_t **config_desc_ret)

Get get device's configuration descriptor.

The USB Host library only caches a device's active configuration descriptor.
This function reads any configuration descriptor of a particular device (specified by bConfigurationValue).
This function will read the specified configuration descriptor via control transfers, and allocate memory to store that descriptor.
Users can call usb_host_free_config_desc() to free the descriptor's memory afterwards.

Note

This function can block

Note

A client must call usb_host_device_open() on the device first

Note

bConfigurationValue starts from index 1

Parameters

client_hdl -- [in] Client handle - usb_host_client_handle_events() should be called repeatedly in a separate task to handle client events
dev_hdl -- [in] Device handle
bConfigurationValue -- [in] Index of device's configuration descriptor to be read
config_desc_ret -- [out] Returned configuration descriptor

Returns

ESP_OK: Configuration descriptor obtained successfully
ESP_ERR_INVALID_ARG: Invalid argument
ESP_ERR_NOT_SUPPORTED: Invalid bConfigurationValue value (the device does not have this configuration value)
ESP_ERR_NO_MEM: Insufficient memory

esp_err_t usb_host_free_config_desc(const usb_config_desc_t *config_desc)

Free a configuration descriptor.

This function frees a configuration descriptor that was returned by usb_host_get_config_desc()

Parameters

config_desc -- [out] Configuration descriptor

Returns

ESP_OK: Configuration descriptor freed successfully
ESP_ERR_INVALID_ARG: Invalid argument

esp_err_t usb_host_interface_claim(usb_host_client_handle_t client_hdl, usb_device_handle_t dev_hdl, uint8_t bInterfaceNumber, uint8_t bAlternateSetting)

Function for a client to claim a device's interface.

A client must claim a device's interface before attempting to communicate with any of its endpoints
Once an interface is claimed by a client, it cannot be claimed by any other client.

Note

This function can block

Parameters

client_hdl -- [in] Client handle
dev_hdl -- [in] Device handle
bInterfaceNumber -- [in] Interface number
bAlternateSetting -- [in] Interface alternate setting number

Returns

ESP_OK: Interface claimed successfully
ESP_ERR_INVALID_ARG: Invalid argument
ESP_ERR_INVALID_STATE: USB Host is not a correct state to claim an interface
ESP_ERR_NOT_FOUND: Interface or EP not found
ESP_ERR_NO_MEM: Insufficient memory

esp_err_t usb_host_interface_release(usb_host_client_handle_t client_hdl, usb_device_handle_t dev_hdl, uint8_t bInterfaceNumber)

Function for a client to release a previously claimed interface.

A client should release a device's interface after it no longer needs to communicate with the interface
A client must release all of its interfaces of a device it has claimed before being able to close the device

Note

This function can block

Parameters

client_hdl -- [in] Client handle
dev_hdl -- [in] Device handle
bInterfaceNumber -- [in] Interface number

Returns

ESP_OK: Interface released successfully
ESP_ERR_INVALID_ARG: Invalid argument
ESP_ERR_INVALID_STATE: Client never opened the USB Device, or interface currently can not be freed
ESP_ERR_NOT_FOUND: Interface number not found in the list of interfaces

esp_err_t usb_host_endpoint_halt(usb_device_handle_t dev_hdl, uint8_t bEndpointAddress)

Halt a particular endpoint.

The device must have been opened by a client
The endpoint must be part of an interface claimed by a client
Once halted, the endpoint must be cleared using usb_host_endpoint_clear() before it can communicate again

Note

This function can block

Parameters

dev_hdl -- [in] Device handle
bEndpointAddress -- [in] Endpoint address

Returns

ESP_OK: Endpoint halted successfully
ESP_ERR_INVALID_ARG: Invalid argument
ESP_ERR_NOT_FOUND: Endpoint address not found
ESP_ERR_INVALID_STATE: Endpoint pipe is not in the correct state/condition to execute a command

esp_err_t usb_host_endpoint_flush(usb_device_handle_t dev_hdl, uint8_t bEndpointAddress)

Flush a particular endpoint.

The device must have been opened by a client
The endpoint must be part of an interface claimed by a client
The endpoint must have been halted (either through a transfer error, or usb_host_endpoint_halt())
Flushing an endpoint will caused an queued up transfers to be canceled

Note

This function can block

Parameters

dev_hdl -- [in] Device handle
bEndpointAddress -- [in] Endpoint address

Returns

ESP_OK: Endpoint flushed successfully
ESP_ERR_INVALID_ARG: Invalid argument
ESP_ERR_NOT_FOUND: Endpoint address not found
ESP_ERR_INVALID_STATE: Endpoint pipe is not in the correct state/condition to execute a command

esp_err_t usb_host_endpoint_clear(usb_device_handle_t dev_hdl, uint8_t bEndpointAddress)

Clear a halt on a particular endpoint.

The device must have been opened by a client
The endpoint must be part of an interface claimed by a client
The endpoint must have been halted (either through a transfer error, or usb_host_endpoint_halt())
If the endpoint has any queued up transfers, clearing a halt will resume their execution

Note

This function can block

Parameters

dev_hdl -- [in] Device handle
bEndpointAddress -- [in] Endpoint address

Returns

ESP_OK: Endpoint cleared successfully
ESP_ERR_INVALID_ARG: Invalid argument
ESP_ERR_NOT_FOUND: Endpoint address not found
ESP_ERR_INVALID_STATE: Endpoint pipe is not in the correct state/condition to execute a command

esp_err_t usb_host_transfer_alloc(size_t data_buffer_size, int num_isoc_packets, usb_transfer_t **transfer)

Allocate a transfer object.

This function allocates a transfer object
Each transfer object has a fixed sized buffer specified on allocation
A transfer object can be re-used indefinitely
A transfer can be submitted using usb_host_transfer_submit() or usb_host_transfer_submit_control()

Parameters

data_buffer_size -- [in] Size of the transfer's data buffer
num_isoc_packets -- [in] Number of isochronous packets in transfer (set to 0 for non-isochronous transfers)
transfer -- [out] Transfer object

Returns

ESP_OK: Transfer object allocated successfully
ESP_ERR_NO_MEM: Insufficient memory

esp_err_t usb_host_transfer_free(usb_transfer_t *transfer)

Free a transfer object.

Free a transfer object previously allocated using usb_host_transfer_alloc()
The transfer must not be in-flight when attempting to free it
If a NULL pointer is passed, this function will simply return ESP_OK

Parameters

transfer -- [in] Transfer object

Returns

ESP_OK: Transfer object freed successfully

esp_err_t usb_host_transfer_submit(usb_transfer_t *transfer)

Submit a non-control transfer.

Submit a transfer to a particular endpoint. The device and endpoint number is specified inside the transfer
The transfer must be properly initialized before submitting
On completion, the transfer's callback will be called from the client's usb_host_client_handle_events() function.

Parameters

transfer -- [in] Initialized transfer object

Returns

ESP_OK: Transfer submitted successfully
ESP_ERR_INVALID_ARG: Invalid argument
ESP_ERR_NOT_FINISHED: Transfer already in-flight
ESP_ERR_NOT_FOUND: Endpoint address not found
ESP_ERR_INVALID_STATE: Endpoint pipe is not in a correct state to submit transfer

esp_err_t usb_host_transfer_submit_control(usb_host_client_handle_t client_hdl, usb_transfer_t *transfer)

Submit a control transfer.

Submit a control transfer to a particular device. The client must have opened the device first
The transfer must be properly initialized before submitting. The first 8 bytes of the transfer's data buffer should contain the control transfer setup packet
On completion, the transfer's callback will be called from the client's usb_host_client_handle_events() function.

Parameters

client_hdl -- [in] Client handle
transfer -- [in] Initialized transfer object

Returns

ESP_OK: Control transfer submitted successfully
ESP_ERR_INVALID_ARG: Invalid argument
ESP_ERR_NOT_FINISHED: Transfer already in-flight
ESP_ERR_NOT_FOUND: Endpoint address not found
ESP_ERR_INVALID_STATE: Endpoint pipe is not in a correct state to submit transfer

Structures

struct usb_host_client_event_msg_t

Client event message.

Client event messages are sent to each client of the USB Host Library in order to notify them of various USB Host Library events such as:

Addition of new devices
Removal of existing devices

Note

The event message structure has a union with members corresponding to each particular event. Based on the event type, only the relevant member field should be accessed.

Public Members

usb_host_client_event_t event: Type of event

uint8_t address: New device's address

struct usb_host_client_event_msg_t::[anonymous]::[anonymous] new_dev: New device info

usb_device_handle_t dev_hdl: The handle of the device that was gone

struct usb_host_client_event_msg_t::[anonymous]::[anonymous] dev_gone: Gone device info

struct usb_host_lib_info_t

Current information about the USB Host Library obtained via usb_host_lib_info()

Public Members

int num_devices: Current number of connected (and enumerated) devices

int num_clients: Current number of registered clients

struct usb_host_config_t

USB Host Library configuration.

Configuration structure of the USB Host Library. Provided in the usb_host_install() function

Public Members

bool skip_phy_setup: If set, the USB Host Library will not configure the USB PHY thus allowing the user to manually configure the USB PHY before calling usb_host_install(). Users should set this if they want to use an external USB PHY. Otherwise, the USB Host Library will automatically configure the internal USB PHY

bool root_port_unpowered: If set, the USB Host Library will not power on the root port on installation. This allows users to power on the root port manually by calling usb_host_lib_set_root_port_power().

int intr_flags: Interrupt flags for the underlying ISR used by the USB Host stack

usb_host_enum_filter_cb_t enum_filter_cb: Enumeration filter callback. Enable CONFIG_USB_HOST_ENABLE_ENUM_FILTER_CALLBACK to use this feature. Set to NULL otherwise.

struct usb_host_client_config_t

USB Host Library Client configuration.

Configuration structure for a USB Host Library client. Provided in usb_host_client_register()

Public Members

bool is_synchronous: Whether the client is asynchronous or synchronous or not. Set to false for now.

int max_num_event_msg: Maximum number of event messages that can be stored (e.g., 3)

usb_host_client_event_cb_t client_event_callback: Client's event callback function

void *callback_arg: Event callback function argument

struct usb_host_client_config_t::[anonymous]::[anonymous] async: Async callback config

Macros

USB_HOST_LIB_EVENT_FLAGS_NO_CLIENTS: All clients have been deregistered from the USB Host Library

USB_HOST_LIB_EVENT_FLAGS_ALL_FREE: The USB Host Library has freed all devices

Type Definitions

typedef struct usb_host_client_handle_s *usb_host_client_handle_t

Handle to a USB Host Library asynchronous client.

An asynchronous client can be registered using usb_host_client_register()

Note

Asynchronous API

typedef void (*usb_host_client_event_cb_t)(const usb_host_client_event_msg_t *event_msg, void *arg)

Client event callback.

Each client of the USB Host Library must register an event callback to receive event messages from the USB Host Library.
The client event callback is run from the context of the clients usb_host_client_handle_events() function

Enumerations

enum usb_host_client_event_t

The type event in a client event message.

Values:

enumerator USB_HOST_CLIENT_EVENT_NEW_DEV: A new device has been enumerated and added to the USB Host Library

enumerator USB_HOST_CLIENT_EVENT_DEV_GONE: A device opened by the client is now gone

Header File

components/usb/include/usb/usb_helpers.h
This header file can be included with:
#include "usb/usb_helpers.h"
This header file is a part of the API provided by the usb component. To declare that your component depends on usb, add the following to your CMakeLists.txt:
REQUIRES usb
or
PRIV_REQUIRES usb

Functions

const usb_standard_desc_t *usb_parse_next_descriptor(const usb_standard_desc_t *cur_desc, uint16_t wTotalLength, int *offset)

Get the next descriptor.

Given a particular descriptor within a full configuration descriptor, get the next descriptor within the configuration descriptor. This is a convenience function that can be used to walk each individual descriptor within a full configuration descriptor.

Parameters

cur_desc -- [in] Current descriptor
wTotalLength -- [in] Total length of the configuration descriptor
offset -- [inout] Byte offset relative to the start of the configuration descriptor. On input, it is the offset of the current descriptor. On output, it is the offset of the returned descriptor.

Returns

usb_standard_desc_t* Next descriptor, NULL if end of configuration descriptor reached

const usb_standard_desc_t *usb_parse_next_descriptor_of_type(const usb_standard_desc_t *cur_desc, uint16_t wTotalLength, uint8_t bDescriptorType, int *offset)

Get the next descriptor of a particular type.

Given a particular descriptor within a full configuration descriptor, get the next descriptor of a particular type (i.e., using the bDescriptorType value) within the configuration descriptor.

Parameters

cur_desc -- [in] Current descriptor
wTotalLength -- [in] Total length of the configuration descriptor
bDescriptorType -- [in] Type of the next descriptor to get
offset -- [inout] Byte offset relative to the start of the configuration descriptor. On input, it is the offset of the current descriptor. On output, it is the offset of the returned descriptor.

Returns

usb_standard_desc_t* Next descriptor, NULL if end descriptor is not found or configuration descriptor reached

int usb_parse_interface_number_of_alternate(const usb_config_desc_t *config_desc, uint8_t bInterfaceNumber)

Get the number of alternate settings for a bInterfaceNumber.

Given a particular configuration descriptor, for a particular bInterfaceNumber, get the number of alternate settings available for that interface (i.e., the max possible value of bAlternateSetting for that bInterfaceNumber).

Parameters

config_desc -- [in] Pointer to the start of a full configuration descriptor
bInterfaceNumber -- [in] Interface number

Returns

int The number of alternate settings that the interface has, -1 if bInterfaceNumber not found

const usb_intf_desc_t *usb_parse_interface_descriptor(const usb_config_desc_t *config_desc, uint8_t bInterfaceNumber, uint8_t bAlternateSetting, int *offset)

Get a particular interface descriptor (using bInterfaceNumber and bAlternateSetting)

Given a full configuration descriptor, get a particular interface descriptor.

Note

To get the number of alternate settings for a particular bInterfaceNumber, call usb_parse_interface_number_of_alternate()

Parameters

config_desc -- [in] Pointer to the start of a full configuration descriptor
bInterfaceNumber -- [in] Interface number
bAlternateSetting -- [in] Alternate setting number
offset -- [out] Byte offset of the interface descriptor relative to the start of the configuration descriptor. Can be NULL.

Returns

const usb_intf_desc_t* Pointer to interface descriptor, NULL if not found.

const usb_ep_desc_t *usb_parse_endpoint_descriptor_by_index(const usb_intf_desc_t *intf_desc, int index, uint16_t wTotalLength, int *offset)

Get an endpoint descriptor within an interface descriptor.

Given an interface descriptor, get the Nth endpoint descriptor of the interface. The number of endpoints in an interface is indicated by the bNumEndpoints field of the interface descriptor.

Note

If bNumEndpoints is 0, it means the interface uses the default endpoint only

Parameters

intf_desc -- [in] Pointer to thee start of an interface descriptor
index -- [in] Endpoint index
wTotalLength -- [in] Total length of the containing configuration descriptor
offset -- [inout] Byte offset relative to the start of the configuration descriptor. On input, it is the offset of the interface descriptor. On output, it is the offset of the endpoint descriptor.

Returns

const usb_ep_desc_t* Pointer to endpoint descriptor, NULL if not found.

const usb_ep_desc_t *usb_parse_endpoint_descriptor_by_address(const usb_config_desc_t *config_desc, uint8_t bInterfaceNumber, uint8_t bAlternateSetting, uint8_t bEndpointAddress, int *offset)

Get an endpoint descriptor based on an endpoint's address.

Given a configuration descriptor, get an endpoint descriptor based on it's bEndpointAddress, bAlternateSetting, and bInterfaceNumber.

Parameters

config_desc -- [in] Pointer to the start of a full configuration descriptor
bInterfaceNumber -- [in] Interface number
bAlternateSetting -- [in] Alternate setting number
bEndpointAddress -- [in] Endpoint address
offset -- [out] Byte offset of the endpoint descriptor relative to the start of the configuration descriptor. Can be NULL

Returns

const usb_ep_desc_t* Pointer to endpoint descriptor, NULL if not found.

void usb_print_device_descriptor(const usb_device_desc_t *devc_desc)

Print device descriptor.

Parameters: devc_desc -- [in] Device descriptor

void usb_print_config_descriptor(const usb_config_desc_t *cfg_desc, print_class_descriptor_cb class_specific_cb)

Print configuration descriptor.

This function prints the full contents of a configuration descriptor (including interface and endpoint descriptors)
When a non-standard descriptor is encountered, this function will call the class_specific_cb if it is provided

Parameters

cfg_desc -- [in] Configuration descriptor
class_specific_cb -- [in] Class specific descriptor callback. Can be NULL

void usb_print_string_descriptor(const usb_str_desc_t *str_desc)

Print a string descriptor.

This function will only print ASCII characters of the UTF-16 encoded string

Parameters: str_desc -- [in] String descriptor

static inline int usb_round_up_to_mps(int num_bytes, int mps)

Round up to an integer multiple of endpoint's MPS.

This is a convenience function to round up a size/length to an endpoint's MPS (Maximum packet size). This is useful when calculating transfer or buffer lengths of IN endpoints.

If MPS <= 0, this function will return 0
If num_bytes <= 0, this function will return 0

Parameters

num_bytes -- [in] Number of bytes
mps -- [in] MPS

Returns

int Round up integer multiple of MPS

Type Definitions

typedef void (*print_class_descriptor_cb)(const usb_standard_desc_t*)

Print class specific descriptor callback.

Optional callback to be provided to usb_print_config_descriptor() function. The callback is called when when a non-standard descriptor is encountered. The callback should decode the descriptor as print it.

Header File

components/usb/include/usb/usb_types_stack.h
This header file can be included with:
#include "usb/usb_types_stack.h"
This header file is a part of the API provided by the usb component. To declare that your component depends on usb, add the following to your CMakeLists.txt:
REQUIRES usb
or
PRIV_REQUIRES usb

Structures

struct usb_parent_dev_info_t

Parent device information.

Public Members

usb_device_handle_t dev_hdl: Device's parent handle

uint8_t port_num: Device's parent port number

struct usb_device_info_t

Basic information of an enumerated device.

Public Members

usb_parent_dev_info_t parent: Device's parent information

usb_speed_t speed: Device's speed

uint8_t dev_addr: Device's address

uint8_t bMaxPacketSize0: The maximum packet size of the device's default endpoint

uint8_t bConfigurationValue: Device's current configuration number

const usb_str_desc_t *str_desc_manufacturer: Pointer to Manufacturer string descriptor (can be NULL)

const usb_str_desc_t *str_desc_product: Pointer to Product string descriptor (can be NULL)

const usb_str_desc_t *str_desc_serial_num: Pointer to Serial Number string descriptor (can be NULL)

struct usb_isoc_packet_desc_t

Isochronous packet descriptor.

If the number of bytes in an Isochronous transfer is larger than the MPS of the endpoint, the transfer is split into multiple packets transmitted at the endpoint's specified interval. An array of Isochronous packet descriptors describes how an Isochronous transfer should be split into multiple packets.

Public Members

int num_bytes: Number of bytes to transmit/receive in the packet. IN packets should be integer multiple of MPS

int actual_num_bytes: Actual number of bytes transmitted/received in the packet

usb_transfer_status_t status: Status of the packet

struct usb_transfer_s

USB transfer structure.

Public Members

uint8_t *const data_buffer: Pointer to data buffer

const size_t data_buffer_size: Size of the data buffer in bytes

int num_bytes: Number of bytes to transfer. Control transfers should include the size of the setup packet. Isochronous transfer should be the total transfer size of all packets. For non-control IN transfers, num_bytes should be an integer multiple of MPS.

int actual_num_bytes: Actual number of bytes transferred

uint32_t flags: Transfer flags

usb_device_handle_t device_handle: Device handle

uint8_t bEndpointAddress: Endpoint Address

usb_transfer_status_t status: Status of the transfer

uint32_t timeout_ms: Timeout (in milliseconds) of the packet (currently not supported yet)

usb_transfer_cb_t callback: Transfer callback

void *context: Context variable for transfer to associate transfer with something

const int num_isoc_packets: Only relevant to Isochronous. Number of service periods (i.e., intervals) to transfer data buffer over.

usb_isoc_packet_desc_t isoc_packet_desc[]: Descriptors for each Isochronous packet

Macros

USB_TRANSFER_FLAG_ZERO_PACK

Terminate Bulk/Interrupt OUT transfer with a zero length packet.

OUT transfers normally terminate when the Host has transferred the exact amount of data it needs to the device. However, for bulk and interrupt OUT transfers, if the transfer size just happened to be a multiple of MPS, it will be impossible to know the boundary between two consecutive transfers to the same endpoint.

Therefore, this flag will cause the transfer to automatically add a zero length packet (ZLP) at the end of the transfer if the following conditions are met:

The target endpoint is a Bulk/Interrupt OUT endpoint (Host to device)
The transfer's length (i.e., transfer.num_bytes) is a multiple of the endpoint's MPS

Otherwise, this flag has no effect.

Users should check whether their target device's class requires a ZLP, as not all Bulk/Interrupt OUT endpoints require them. For example:

For MSC Bulk Only Transport class, the Host MUST NEVER send a ZLP. Bulk transfer boundaries are determined by the CBW and CSW instead
For CDC Ethernet, the Host MUST ALWAYS send a ZLP if a segment (i.e., a transfer) is a multiple of MPS (See 3.3.1 Segment Delineation)

Note

See USB2.0 specification 5.7.3 and 5.8.3 for more details

Note

IN transfers normally terminate when the Host as receive the exact amount of data it needs (must be multiple of MPS) or the endpoint sends a short packet to the Host (For bulk OUT only). Indicates that a bulk OUT transfers should always terminate with a short packet, even if it means adding an extra zero length packet

Type Definitions

typedef struct usb_device_handle_s *usb_device_handle_t: Handle of a USB Device connected to a USB Host.

typedef bool (*usb_host_enum_filter_cb_t)(const usb_device_desc_t *dev_desc, uint8_t *bConfigurationValue)

Enumeration filter callback.

This callback is called at the beginning of the enumeration process for a newly attached device. Through this callback, users are able to:

filter which devices should be enumerated
select the configuration number to use when enumerating the device

The device descriptor is passed to this callback to allow users to filter devices based on Vendor ID, Product ID, and class code.

Attention: This callback must be non-blocking
Attention: This callback must not submit any USB transfers

Param dev_desc

[in] Device descriptor of the device to enumerate

Param bConfigurationValue

[out] Configuration number to use when enumerating the device (starts with 1)

Return

bool

true: USB device will be enumerated
false: USB device will not be enumerated

typedef struct usb_transfer_s usb_transfer_t

USB transfer structure.

This structure is used to represent a transfer from a software client to an endpoint over the USB bus. Some of the fields are made const on purpose as they are fixed on allocation. Users should call the appropriate USB Host Library function to allocate a USB transfer structure instead of allocating this structure themselves.

The transfer type is inferred from the endpoint this transfer is sent to. Depending on the transfer type, users should note the following:

Bulk: This structure represents a single bulk transfer. If the number of bytes exceeds the endpoint's MPS, the transfer will be split into multiple MPS sized packets followed by a short packet.
Control: This structure represents a single control transfer. This first 8 bytes of the data_buffer must be filled with the setup packet (see usb_setup_packet_t). The num_bytes field should be the total size of the transfer (i.e., size of setup packet + wLength).
Interrupt: Represents an interrupt transfer. If num_bytes exceeds the MPS of the endpoint, the transfer will be split into multiple packets, and each packet is transferred at the endpoint's specified interval.
Isochronous: Represents a stream of bytes that should be transferred to an endpoint at a fixed rate. The transfer is split into packets according to the each isoc_packet_desc. A packet is transferred at each interval of the endpoint. If an entire ISOC URB was transferred without error (skipped packets do not count as errors), the URB's overall status and the status of each packet descriptor will be updated, and the actual_num_bytes reflects the total bytes transferred over all packets. If the ISOC URB encounters an error, the entire URB is considered erroneous so only the overall status will updated.

Note

For Bulk/Control/Interrupt IN transfers, the num_bytes must be a integer multiple of the endpoint's MPS

Note

This structure should be allocated via usb_host_transfer_alloc()

Note

Once the transfer has be submitted, users should not modify the structure until the transfer has completed

typedef void (*usb_transfer_cb_t)(usb_transfer_t *transfer): USB transfer completion callback.

Enumerations

enum usb_speed_t

USB Standard Speeds.

Values:

enumerator USB_SPEED_LOW: USB Low Speed (1.5 Mbit/s)

enumerator USB_SPEED_FULL: USB Full Speed (12 Mbit/s)

enumerator USB_SPEED_HIGH: USB High Speed (480 Mbit/s)

enum usb_transfer_type_t

The type of USB transfer.

Note

The enum values need to match the bmAttributes field of an EP descriptor

Values:

enumerator USB_TRANSFER_TYPE_CTRL

enumerator USB_TRANSFER_TYPE_ISOCHRONOUS

enumerator USB_TRANSFER_TYPE_BULK

enumerator USB_TRANSFER_TYPE_INTR

enum usb_transfer_status_t

The status of a particular transfer.

Values:

enumerator USB_TRANSFER_STATUS_COMPLETED: The transfer was successful (but may be short)

enumerator USB_TRANSFER_STATUS_ERROR: The transfer failed because due to excessive errors (e.g. no response or CRC error)

enumerator USB_TRANSFER_STATUS_TIMED_OUT: The transfer failed due to a time out

enumerator USB_TRANSFER_STATUS_CANCELED: The transfer was canceled

enumerator USB_TRANSFER_STATUS_STALL: The transfer was stalled

enumerator USB_TRANSFER_STATUS_OVERFLOW: The transfer as more data was sent than was requested

enumerator USB_TRANSFER_STATUS_SKIPPED: ISOC packets only. The packet was skipped due to system latency or bus overload

enumerator USB_TRANSFER_STATUS_NO_DEVICE: The transfer failed because the target device is gone

Header File

components/usb/include/usb/usb_types_ch9.h
This header file can be included with:
#include "usb/usb_types_ch9.h"
This header file is a part of the API provided by the usb component. To declare that your component depends on usb, add the following to your CMakeLists.txt:
REQUIRES usb
or
PRIV_REQUIRES usb

Unions

union usb_setup_packet_t

#include <usb_types_ch9.h>

Structure representing a USB control transfer setup packet.

See Table 9-2 of USB2.0 specification for more details

Public Members

uint8_t bmRequestType: Characteristics of request

uint8_t bRequest: Specific request

uint16_t wValue: Word-sized field that varies according to request

uint16_t wIndex: Word-sized field that varies according to request; typically used to pass an index or offset

uint16_t wLength: Number of bytes to transfer if there is a data stage

struct usb_setup_packet_t::[anonymous] USB_DESC_ATTR: USB descriptor attributes

uint8_t val[USB_SETUP_PACKET_SIZE]: Descriptor value

union usb_device_status_t

#include <usb_types_ch9.h>

Structure representing a USB device status.

See Figures 9-4 Information Returned by a GetStatus() Request to a Device of USB2.0 specification for more details

Public Members

uint16_t self_powered: 1 - Device is currently self-powered, 0 - bus powered

uint16_t remote_wakeup: 1 - the ability of the device to signal remote wakeup is enabled, 0 - the ability of the device to signal remote wakeup is disabled.

uint16_t reserved: reserved

struct usb_device_status_t::[anonymous] USB_DESC_ATTR: Packed

uint16_t val: Device status value

union usb_standard_desc_t

#include <usb_types_ch9.h>

USB standard descriptor.

All USB standard descriptors start with these two bytes. Use this type when traversing over configuration descriptors

Public Members

uint8_t bLength: Size of the descriptor in bytes

uint8_t bDescriptorType: Descriptor Type

struct usb_standard_desc_t::[anonymous] USB_DESC_ATTR: USB descriptor attributes

uint8_t val[USB_STANDARD_DESC_SIZE]: Descriptor value

union usb_device_desc_t

#include <usb_types_ch9.h>

Structure representing a USB device descriptor.

See Table 9-8 of USB2.0 specification for more details

Public Members

uint8_t bLength: Size of the descriptor in bytes

uint8_t bDescriptorType: DEVICE Descriptor Type

uint16_t bcdUSB: USB Specification Release Number in Binary-Coded Decimal (i.e., 2.10 is 210H)

uint8_t bDeviceClass: Class code (assigned by the USB-IF)

uint8_t bDeviceSubClass: Subclass code (assigned by the USB-IF)

uint8_t bDeviceProtocol: Protocol code (assigned by the USB-IF)

uint8_t bMaxPacketSize0: Maximum packet size for endpoint zero (only 8, 16, 32, or 64 are valid)

uint16_t idVendor: Vendor ID (assigned by the USB-IF)

uint16_t idProduct: Product ID (assigned by the manufacturer)

uint16_t bcdDevice: Device release number in binary-coded decimal

uint8_t iManufacturer: Index of string descriptor describing manufacturer

uint8_t iProduct: Index of string descriptor describing product

uint8_t iSerialNumber: Index of string descriptor describing the device’s serial number

uint8_t bNumConfigurations: Number of possible configurations

struct usb_device_desc_t::[anonymous] USB_DESC_ATTR: USB descriptor attributes

uint8_t val[USB_DEVICE_DESC_SIZE]: Descriptor value

union usb_config_desc_t

#include <usb_types_ch9.h>

Structure representing a short USB configuration descriptor.

See Table 9-10 of USB2.0 specification for more details

Note

The full USB configuration includes all the interface and endpoint descriptors of that configuration.

Public Members

uint8_t bLength: Size of the descriptor in bytes

uint8_t bDescriptorType: CONFIGURATION Descriptor Type

uint16_t wTotalLength: Total length of data returned for this configuration

uint8_t bNumInterfaces: Number of interfaces supported by this configuration

uint8_t bConfigurationValue: Value to use as an argument to the SetConfiguration() request to select this configuration

uint8_t iConfiguration: Index of string descriptor describing this configuration

uint8_t bmAttributes: Configuration characteristics

uint8_t bMaxPower: Maximum power consumption of the USB device from the bus in this specific configuration when the device is fully operational.

struct usb_config_desc_t::[anonymous] USB_DESC_ATTR: USB descriptor attributes

uint8_t val[USB_CONFIG_DESC_SIZE]: Descriptor value

union usb_iad_desc_t

#include <usb_types_ch9.h>

Structure representing a USB interface association descriptor.

Public Members

uint8_t bLength: Size of the descriptor in bytes

uint8_t bDescriptorType: INTERFACE ASSOCIATION Descriptor Type

uint8_t bFirstInterface: Interface number of the first interface that is associated with this function

uint8_t bInterfaceCount: Number of contiguous interfaces that are associated with this function

uint8_t bFunctionClass: Class code (assigned by USB-IF)

uint8_t bFunctionSubClass: Subclass code (assigned by USB-IF)

uint8_t bFunctionProtocol: Protocol code (assigned by USB-IF)

uint8_t iFunction: Index of string descriptor describing this function

struct usb_iad_desc_t::[anonymous] USB_DESC_ATTR: USB descriptor attributes

uint8_t val[USB_IAD_DESC_SIZE]: Descriptor value

union usb_intf_desc_t

#include <usb_types_ch9.h>

Structure representing a USB interface descriptor.

See Table 9-12 of USB2.0 specification for more details

Public Members

uint8_t bLength: Size of the descriptor in bytes

uint8_t bDescriptorType: INTERFACE Descriptor Type

uint8_t bInterfaceNumber: Number of this interface.

uint8_t bAlternateSetting: Value used to select this alternate setting for the interface identified in the prior field

uint8_t bNumEndpoints: Number of endpoints used by this interface (excluding endpoint zero).

uint8_t bInterfaceClass: Class code (assigned by the USB-IF)

uint8_t bInterfaceSubClass: Subclass code (assigned by the USB-IF)

uint8_t bInterfaceProtocol: Protocol code (assigned by the USB)

uint8_t iInterface: Index of string descriptor describing this interface

struct usb_intf_desc_t::[anonymous] USB_DESC_ATTR: USB descriptor attributes

uint8_t val[USB_INTF_DESC_SIZE]: Descriptor value

union usb_ep_desc_t

#include <usb_types_ch9.h>

Structure representing a USB endpoint descriptor.

See Table 9-13 of USB2.0 specification for more details

Public Members

uint8_t bLength: Size of the descriptor in bytes

uint8_t bDescriptorType: ENDPOINT Descriptor Type

uint8_t bEndpointAddress: The address of the endpoint on the USB device described by this descriptor

uint8_t bmAttributes: This field describes the endpoint’s attributes when it is configured using the bConfigurationValue.

uint16_t wMaxPacketSize: Maximum packet size this endpoint is capable of sending or receiving when this configuration is selected.

uint8_t bInterval: Interval for polling Isochronous and Interrupt endpoints. Expressed in frames or microframes depending on the device operating speed (1 ms for Low-Speed and Full-Speed or 125 us for USB High-Speed and above).

struct usb_ep_desc_t::[anonymous] USB_DESC_ATTR: USB descriptor attributes

uint8_t val[USB_EP_DESC_SIZE]: Descriptor value

union usb_str_desc_t

#include <usb_types_ch9.h>

Structure representing a USB string descriptor.

Public Members

uint8_t bLength: Size of the descriptor in bytes

uint8_t bDescriptorType: STRING Descriptor Type

uint16_t wData[]: UTF-16LE encoded

struct usb_str_desc_t::[anonymous] USB_DESC_ATTR: USB descriptor attributes

uint8_t val[USB_STR_DESC_SIZE]: Descriptor value

Macros

USB_DESC_ATTR

USB_B_DESCRIPTOR_TYPE_DEVICE: Descriptor types from USB2.0 specification table 9.5.

USB_B_DESCRIPTOR_TYPE_CONFIGURATION

USB_B_DESCRIPTOR_TYPE_STRING

USB_B_DESCRIPTOR_TYPE_INTERFACE

USB_B_DESCRIPTOR_TYPE_ENDPOINT

USB_B_DESCRIPTOR_TYPE_DEVICE_QUALIFIER

USB_B_DESCRIPTOR_TYPE_OTHER_SPEED_CONFIGURATION

USB_B_DESCRIPTOR_TYPE_INTERFACE_POWER

USB_B_DESCRIPTOR_TYPE_OTG: Descriptor types from USB 2.0 ECN.

USB_B_DESCRIPTOR_TYPE_DEBUG

USB_B_DESCRIPTOR_TYPE_INTERFACE_ASSOCIATION

USB_B_DESCRIPTOR_TYPE_SECURITY: Descriptor types from Wireless USB spec.

USB_B_DESCRIPTOR_TYPE_KEY

USB_B_DESCRIPTOR_TYPE_ENCRYPTION_TYPE

USB_B_DESCRIPTOR_TYPE_BOS

USB_B_DESCRIPTOR_TYPE_DEVICE_CAPABILITY

USB_B_DESCRIPTOR_TYPE_WIRELESS_ENDPOINT_COMP

USB_B_DESCRIPTOR_TYPE_WIRE_ADAPTER

USB_B_DESCRIPTOR_TYPE_RPIPE

USB_B_DESCRIPTOR_TYPE_CS_RADIO_CONTROL

USB_B_DESCRIPTOR_TYPE_PIPE_USAGE: Descriptor types from UAS specification.

USB_SETUP_PACKET_SIZE: Size of a USB control transfer setup packet in bytes.

USB_BM_REQUEST_TYPE_DIR_OUT: Bit masks belonging to the bmRequestType field of a setup packet.

USB_BM_REQUEST_TYPE_DIR_IN

USB_BM_REQUEST_TYPE_TYPE_STANDARD

USB_BM_REQUEST_TYPE_TYPE_CLASS

USB_BM_REQUEST_TYPE_TYPE_VENDOR

USB_BM_REQUEST_TYPE_TYPE_RESERVED

USB_BM_REQUEST_TYPE_TYPE_MASK

USB_BM_REQUEST_TYPE_RECIP_DEVICE

USB_BM_REQUEST_TYPE_RECIP_INTERFACE

USB_BM_REQUEST_TYPE_RECIP_ENDPOINT

USB_BM_REQUEST_TYPE_RECIP_OTHER

USB_BM_REQUEST_TYPE_RECIP_MASK

USB_B_REQUEST_GET_STATUS: Bit masks belonging to the bRequest field of a setup packet.

USB_B_REQUEST_CLEAR_FEATURE

USB_B_REQUEST_SET_FEATURE

USB_B_REQUEST_SET_ADDRESS

USB_B_REQUEST_GET_DESCRIPTOR

USB_B_REQUEST_SET_DESCRIPTOR

USB_B_REQUEST_GET_CONFIGURATION

USB_B_REQUEST_SET_CONFIGURATION

USB_B_REQUEST_GET_INTERFACE

USB_B_REQUEST_SET_INTERFACE

USB_B_REQUEST_SYNCH_FRAME

USB_W_VALUE_DT_DEVICE: Bit masks belonging to the wValue field of a setup packet.

USB_W_VALUE_DT_CONFIG

USB_W_VALUE_DT_STRING

USB_W_VALUE_DT_INTERFACE

USB_W_VALUE_DT_ENDPOINT

USB_W_VALUE_DT_DEVICE_QUALIFIER

USB_W_VALUE_DT_OTHER_SPEED_CONFIG

USB_W_VALUE_DT_INTERFACE_POWER

USB_SETUP_PACKET_INIT_GET_STATUS(setup_pkt_ptr)

Initializer for a GET_STATUS request.

Sets the address of a connected device

USB_SETUP_PACKET_INIT_SET_ADDR(setup_pkt_ptr, addr)

Initializer for a SET_ADDRESS request.

Sets the address of a connected device

USB_SETUP_PACKET_INIT_GET_DEVICE_DESC(setup_pkt_ptr): Initializer for a request to get a device's device descriptor.

USB_SETUP_PACKET_INIT_GET_CONFIG(setup_pkt_ptr): Initializer for a request to get a device's current configuration number.

USB_SETUP_PACKET_INIT_GET_CONFIG_DESC(setup_pkt_ptr, desc_index, desc_len)

Initializer for a request to get one of the device's current configuration descriptor.

desc_index indicates the configuration's index number
Number of bytes of the configuration descriptor to get

USB_SETUP_PACKET_INIT_SET_CONFIG(setup_pkt_ptr, config_num): Initializer for a request to set a device's current configuration number.

USB_SETUP_PACKET_INIT_SET_INTERFACE(setup_pkt_ptr, intf_num, alt_setting_num): Initializer for a request to set an interface's alternate setting.

USB_SETUP_PACKET_INIT_GET_STR_DESC(setup_pkt_ptr, string_index, lang_id, desc_len): Initializer for a request to get an string descriptor.

USB_STANDARD_DESC_SIZE: Size of dummy USB standard descriptor.

USB_DEVICE_DESC_SIZE: Size of a USB device descriptor in bytes.

USB_CLASS_PER_INTERFACE: Possible base class values of the bDeviceClass field of a USB device descriptor.

USB_CLASS_AUDIO

USB_CLASS_COMM

USB_CLASS_HID

USB_CLASS_PHYSICAL

USB_CLASS_STILL_IMAGE

USB_CLASS_PRINTER

USB_CLASS_MASS_STORAGE

USB_CLASS_HUB

USB_CLASS_CDC_DATA

USB_CLASS_CSCID

USB_CLASS_CONTENT_SEC

USB_CLASS_VIDEO

USB_CLASS_WIRELESS_CONTROLLER

USB_CLASS_PERSONAL_HEALTHCARE

USB_CLASS_AUDIO_VIDEO

USB_CLASS_BILLBOARD

USB_CLASS_USB_TYPE_C_BRIDGE

USB_CLASS_MISC

USB_CLASS_APP_SPEC

USB_CLASS_VENDOR_SPEC

USB_SUBCLASS_VENDOR_SPEC: Vendor specific subclass code.

USB_CONFIG_DESC_SIZE: Size of a short USB configuration descriptor in bytes.

Note

The size of a full USB configuration includes all the interface and endpoint descriptors of that configuration.

USB_BM_ATTRIBUTES_ONE

Bit masks belonging to the bmAttributes field of a configuration descriptor.

Must be set

USB_BM_ATTRIBUTES_SELFPOWER: Self powered

USB_BM_ATTRIBUTES_WAKEUP: Can wake-up

USB_BM_ATTRIBUTES_BATTERY: Battery powered

USB_IAD_DESC_SIZE: Size of a USB interface association descriptor in bytes.

USB_INTF_DESC_SIZE: Size of a USB interface descriptor in bytes.

USB_EP_DESC_SIZE: Size of a USB endpoint descriptor in bytes.

USB_B_ENDPOINT_ADDRESS_EP_NUM_MASK: Bit masks belonging to the bEndpointAddress field of an endpoint descriptor.

USB_B_ENDPOINT_ADDRESS_EP_DIR_MASK

USB_W_MAX_PACKET_SIZE_MPS_MASK: Bit masks belonging to the wMaxPacketSize field of endpoint descriptor.

USB_W_MAX_PACKET_SIZE_MULT_MASK

USB_BM_ATTRIBUTES_XFERTYPE_MASK: Bit masks belonging to the bmAttributes field of an endpoint descriptor.

USB_BM_ATTRIBUTES_XFER_CONTROL

USB_BM_ATTRIBUTES_XFER_ISOC

USB_BM_ATTRIBUTES_XFER_BULK

USB_BM_ATTRIBUTES_XFER_INT

USB_BM_ATTRIBUTES_SYNCTYPE_MASK

USB_BM_ATTRIBUTES_SYNC_NONE

USB_BM_ATTRIBUTES_SYNC_ASYNC

USB_BM_ATTRIBUTES_SYNC_ADAPTIVE

USB_BM_ATTRIBUTES_SYNC_SYNC

USB_BM_ATTRIBUTES_USAGETYPE_MASK

USB_BM_ATTRIBUTES_USAGE_DATA

USB_BM_ATTRIBUTES_USAGE_FEEDBACK

USB_BM_ATTRIBUTES_USAGE_IMPLICIT_FB

USB_EP_DESC_GET_XFERTYPE(desc_ptr): Macro helpers to get information about an endpoint from its descriptor.

USB_EP_DESC_GET_EP_NUM(desc_ptr)

USB_EP_DESC_GET_EP_DIR(desc_ptr)

USB_EP_DESC_GET_MPS(desc_ptr)

USB_EP_DESC_GET_MULT(desc_ptr)

USB_EP_DESC_GET_SYNCTYPE(desc_ptr)

USB_EP_DESC_GET_USAGETYPE(desc_ptr)

USB_STR_DESC_SIZE: Size of a short USB string descriptor in bytes.

Enumerations

enum usb_device_state_t

USB2.0 device states.

See Table 9-1 of USB2.0 specification for more details

Note

The USB_DEVICE_STATE_NOT_ATTACHED is not part of the USB2.0 specification, but is a catch all state for devices that need to be cleaned up after a sudden disconnection or port error.

Values:

enumerator USB_DEVICE_STATE_NOT_ATTACHED: The device was previously configured or suspended, but is no longer attached (either suddenly disconnected or a port error)

enumerator USB_DEVICE_STATE_ATTACHED: Device is attached to the USB, but is not powered.

enumerator USB_DEVICE_STATE_POWERED: Device is attached to the USB and powered, but has not been reset.

enumerator USB_DEVICE_STATE_DEFAULT: Device is attached to the USB and powered and has been reset, but has not been assigned a unique address. Device responds at the default address.

enumerator USB_DEVICE_STATE_ADDRESS: Device is attached to the USB, powered, has been reset, and a unique device address has been assigned. Device is not configured.

enumerator USB_DEVICE_STATE_CONFIGURED: Device is attached to the USB, powered, has been reset, has a unique address, is configured, and is not suspended. The host may now use the function provided by the device.

enumerator USB_DEVICE_STATE_SUSPENDED: Device is, at minimum, attached to the USB and is powered and has not seen bus activity for 3 ms. It may also have a unique address and be configured for use. However, because the device is suspended, the host may not use the device’s function.

Maintainers Notes 

Note

For more details regarding the internal implementation details of the USB Host stack, please refer to USB Host Maintainers Notes (Introduction).

Was this page helpful?

Thank you! We received your feedback.
If you have any comments, fill in Espressif Documentation Feedback Form.

We value your feedback.
Let us know how we can improve this page by filling in Espressif Documentation Feedback Form.
