Agent Code Generation and EV-MUX Closed-Loop Test
This guide is normative for AI agents that generate ESP-VISION application code. Treat the target as an ESP32 microcontroller running the ESP-VISION build of MicroPython v1.28.0, not as a PC running CPython. Use only APIs present in this knowledge pack, enabled for the selected board, or demonstrated by a repository example; never assume that a desktop standard-library module, pip package, native wheel, operating-system service, subprocess, or PC filesystem is available on the device.
Dependency Rules
The default ESP-VISION firmware cannot dynamically install dependencies from requirements.txt and does not include device-side mip. Generated target code must not invoke pip, parse requirements.txt, call mip.install(), or silently depend on an unverified third-party package. If a required module is not in the knowledge pack, either rewrite the solution with supported modules or explicitly state that it must be copied to /lib with a host tool, precompiled as compatible .mpy, frozen into custom firmware, or implemented as a native module before the script can run.
Host-side tooling is separate from target code. A PC utility may use CPython packages such as pyserial, but label that code as host-only and never import those packages from the ESP-VISION script.
All-in-One Output
Unless the user asks for a package or a multi-file architecture, return one self-contained main.py for the device. Put supported imports, constants, initialization, application logic, the main loop or bounded test, error handling, and cleanup in that file. Avoid helper modules that the user would have to create separately. Models and other binary assets may remain separate files, but list their exact device paths and deployment prerequisites.
Prefer bounded, observable verification code before an infinite product loop. Print a unique success marker only after the camera, model, storage, network, or other requested operation has really succeeded. The following target-side smoke test is an all-in-one MicroPython script and prints EVTEST:OK only after capturing a frame:
import gc
import sensor
def main():
print("EVTEST:START")
sensor.reset()
try:
sensor.set_pixformat(sensor.RGB565)
sensor.set_framesize(sensor.QQVGA)
sensor.skip_frames(time=500)
image = sensor.snapshot()
width = image.width()
height = image.height()
finally:
sensor.shutdown()
print("EVTEST:OK {}x{} heap={}".format(
width, height, gc.mem_free()))
main()
USB-OTG CDC and USJ Transport Contract
ESP-VISION carries the same EV-MUX protocol over USB-OTG CDC (sink cdc) and USB-Serial-JTAG (sink usj). Open exactly one device port for a test. Opening the CDC port with DTR asserted makes CDC the automatic route; otherwise supported boards fall back to USJ. Do not open both ports or leave another serial monitor attached while testing. USB baud rate is not part of the protocol, although host serial APIs still require a placeholder baud value.
Every frame is 0x1e followed by EVMUX/1 h=<metadata_len> p=<payload_len> c=<crc32>\r\n, exactly h bytes of UTF-8 JSON metadata, exactly p payload bytes, and a final 0x1f. Lengths, not delimiters, define the metadata and payload boundaries. Device frames carry the payload CRC32; a host command may send a zero CRC, although computing it is recommended. A receiver must resynchronize on 0x1e, validate lengths and CRC, then dispatch every frame by metadata.channel rather than by USB port or arrival order.
The minimum closed loop is: open the selected port; exchange hello and capabilities; verify firmware.id == "esp-vision" and the negotiated evMuxVersion; query transport.state; stop the current script to reach the REPL; upload one complete device script with script.write; start it with script.run; and require an expected marker on repl.stdout. A script.run response only means the script was queued, so it is not a successful application test by itself.
The following host-only CPython script implements that complete loop for either USB-OTG CDC or USJ. Install pyserial on the PC with python -m pip install pyserial, save this as one file, close other serial tools, and run it with the selected device port, for example python evmux_smoke.py /dev/ttyACM0. The uploaded MicroPython program is embedded in the host script, so no second source file is required.
#!/usr/bin/env python3
import argparse
import base64
import json
import re
import sys
import time
import zlib
import serial
DEVICE_SCRIPT = """\
import gc
import sensor
def main():
print("EVTEST:START")
sensor.reset()
try:
sensor.set_pixformat(sensor.RGB565)
sensor.set_framesize(sensor.QQVGA)
sensor.skip_frames(time=500)
image = sensor.snapshot()
width = image.width()
height = image.height()
finally:
sensor.shutdown()
print("EVTEST:OK {}x{} heap={}".format(
width, height, gc.mem_free()))
main()
"""
SOF = b"\x1e"
EOF = b"\x1f"
HEADER_RE = re.compile(
rb"EVMUX/1 h=([0-9]+) p=([0-9]+) c=([0-9A-Fa-f]{8})\r\n")
MAX_METADATA = 64 * 1024
MAX_PAYLOAD = 16 * 1024 * 1024
WRITE_CHUNK = 768
class EvMux:
def __init__(self, port):
self.port = port
self.next_seq = 1
self.text_tail = bytearray()
def _read_exact(self, size, deadline):
data = bytearray()
while len(data) < size:
if time.monotonic() >= deadline:
raise TimeoutError("timed out while reading EV-MUX frame")
part = self.port.read(size - len(data))
if part:
data.extend(part)
return bytes(data)
def read_frame(self, deadline):
while time.monotonic() < deadline:
if self.port.read(1) != SOF:
continue
header = bytearray()
while len(header) < 80:
char = self._read_exact(1, deadline)
header.extend(char)
if char == b"\n":
break
match = HEADER_RE.fullmatch(bytes(header))
if match is None:
continue
metadata_len = int(match.group(1))
payload_len = int(match.group(2))
expected_crc = int(match.group(3), 16)
if not 0 < metadata_len <= MAX_METADATA:
raise RuntimeError("invalid metadata length: {}".format(metadata_len))
if not 0 <= payload_len <= MAX_PAYLOAD:
raise RuntimeError("invalid payload length: {}".format(payload_len))
metadata_bytes = self._read_exact(metadata_len, deadline)
payload = self._read_exact(payload_len, deadline)
if self._read_exact(1, deadline) != EOF:
raise RuntimeError("invalid EV-MUX EOF")
actual_crc = zlib.crc32(payload) & 0xFFFFFFFF
if expected_crc and actual_crc != expected_crc:
raise RuntimeError("EV-MUX payload CRC mismatch")
metadata = json.loads(metadata_bytes.decode("utf-8"))
return metadata, payload
raise TimeoutError("timed out waiting for EV-MUX frame")
def send_request(self, channel, method, body):
seq = self.next_seq
self.next_seq += 1
payload = json.dumps(body, separators=(",", ":")).encode("utf-8")
metadata = {
"sid": "debug" if channel == "debug.rpc" else "user",
"seq": seq,
"channel": channel,
"type": "req",
"method": method,
"encoding": "json",
"ts_ms": int(time.monotonic() * 1000),
}
metadata_bytes = json.dumps(
metadata, separators=(",", ":")).encode("utf-8")
crc = zlib.crc32(payload) & 0xFFFFFFFF
header = "EVMUX/1 h={} p={} c={:08X}\r\n".format(
len(metadata_bytes), len(payload), crc).encode("ascii")
self.port.write(SOF + header + metadata_bytes + payload + EOF)
self.port.flush()
return seq
def _observe(self, metadata, payload):
channel = metadata.get("channel")
if channel in ("repl.stdout", "repl.stderr", "log.idf"):
self.text_tail.extend(payload)
del self.text_tail[:-8192]
text = payload.decode("utf-8", errors="replace")
sys.stdout.write("[{}] {}".format(channel, text))
sys.stdout.flush()
def rpc(self, channel, method, body, timeout=10):
seq = self.send_request(channel, method, body)
deadline = time.monotonic() + timeout
while True:
metadata, payload = self.read_frame(deadline)
self._observe(metadata, payload)
if (metadata.get("channel") != channel
or metadata.get("type") != "rsp"
or metadata.get("seq") != seq):
continue
if metadata.get("encoding") != "json":
raise RuntimeError("unexpected binary RPC response")
result = json.loads(payload.decode("utf-8"))
if not result.get("ok"):
raise RuntimeError("{} failed: {}".format(method, result))
return result
def wait_for_text(self, marker, timeout=15):
deadline = time.monotonic() + timeout
while marker not in self.text_tail:
metadata, payload = self.read_frame(deadline)
self._observe(metadata, payload)
return bytes(self.text_tail)
def upload_script(mux, path, source):
content = source.encode("utf-8")
for offset in range(0, len(content), WRITE_CHUNK):
chunk = content[offset:offset + WRITE_CHUNK]
result = mux.rpc("user.rpc", "script.write", {
"path": path,
"mode": "overwrite",
"encoding": "utf-8",
"contentBase64": base64.b64encode(chunk).decode("ascii"),
"offset": offset,
"totalBytes": len(content),
})
expected_complete = offset + len(chunk) == len(content)
if result.get("complete") != expected_complete:
raise RuntimeError("unexpected script.write completion state")
def main():
parser = argparse.ArgumentParser(
description="ESP-VISION EV-MUX USB/USJ closed-loop smoke test")
parser.add_argument("port", help="USB-OTG CDC or USB-Serial-JTAG port")
args = parser.parse_args()
with serial.Serial(
args.port, baudrate=115200, timeout=0.2, write_timeout=5) as port:
try:
port.dtr = True
except (OSError, serial.SerialException):
pass
port.reset_input_buffer()
time.sleep(0.1)
mux = EvMux(port)
hello = mux.rpc("user.rpc", "hello", {})
if hello.get("firmware", {}).get("id") != "esp-vision":
raise RuntimeError("connected device is not ESP-VISION")
capabilities = mux.rpc("user.rpc", "capabilities", {})
version = capabilities.get("protocol", {}).get("evMuxVersion")
if version != 3:
raise RuntimeError("unsupported EV-MUX version: {}".format(version))
required = {"user.rpc", "debug.rpc", "repl.stdout"}
if not required.issubset(set(capabilities.get("channels", []))):
raise RuntimeError("required EV-MUX channels are unavailable")
state = mux.rpc("debug.rpc", "transport.state", {})
print("routes: user={user[route]} debug={debug[route]}".format(**state))
mux.rpc("user.rpc", "device.control", {"action": "stop"})
mux.wait_for_text(b">>>", timeout=10)
path = "/evmux_smoke.py"
upload_script(mux, path, DEVICE_SCRIPT)
mux.rpc("user.rpc", "script.run", {"path": path})
mux.wait_for_text(b"EVTEST:OK", timeout=20)
print("\nPASS: EV-MUX upload, execution, camera capture, and stdout verified")
if __name__ == "__main__":
main()
This test deliberately treats a timeout, malformed frame, rejected route, negative RPC response, missing camera marker, or unsupported protocol version as a failure. For product integration, retain the same framing and correlation rules, keep reading unrelated events while awaiting an RPC sequence, handle VM_BUSY and VM_TIMEOUT explicitly, and never report success until the expected device-side output or result has been observed.
